SHEET METAL MANUFACTURING PLANT
Fiber Laser Cutting Machine
Laser power - 1500 W, wave length – 1070P
Machine Capacity:
- Carbon steel - Up to 16mm
- Stainless steel – up to 8mm;
- Aluminum – up to 5mm.
Materials
mild steel, stainless steel, aluminum alloy, brass, silicon steel, titanium alloy copper and other metals.
CNC Hydraulic Press Brake (Torsion Bar type) -160 MT
Capacity – 160 MT
Bending capacity:
Steel - 3000x6.0, 2500x8.0 mm
Stainless Steel - 3000x3.2, 2500x4.0 mm
Machine shop comprising Center lathes, drilling, slotting, cutting machines
Lathe Machine
Radial Drilling Machine
Power Saw Machine
Tapping Machine
WELDING PRODUCTS MANUFACTURING PLANT
Welding Electrode Plant
Laser power - 1500 W, wave length – 1070P
Sizes: 5.0mm dia, 4.0mm dia, 3.15mm dia, 2.5mm dia Capacity: 8T per shift.
Wire Drawing Machine
Features:
- Inlet Wire Diameter: 6.0 - 5.5 mm
- Outlet Wire Diameter: 5.0/4.0/3.15/2.5/2.0 mm
Copper coated MIG (CO2 Wire) Plant
Wire Sizes:
1.2mm dia, 1.0mm dia, 0.8mm dia
Capacity:
2.5T per shift.
Baking Oven with Panel Board
Capacity: 250 ° C/ 2 T Per Charge
500 ° C/ 1.5 T Per Charge
Wire straightening
& Cutting machine with coil stand
Extruder Plant
Layer Winding Machine
Spool size: 300 dia plastic spools
Capacity: 2T/shift
MECHANICAL AND CHEMICAL TESTING LABORATORY
Universal Testing Machine
Capacity: 400 KN
Pendulum Impact Testing Machine
Range: 300J (Charpy Test) & 168 J for IZOD Test
